IOMM AGZB1 AGZ 010B through 034B 31
ACZ/AGZ Dimensions and Weights
Table 14, Packaged Chiller, Dimensions and Weights
CENTER OF GRAVITY
(IN.)
LIFTING CORNER
WEIGHTS (LBS)
MOUNTING CORNER
WEIGHTS (LBS.)
AGZ
UNIT
SIZE
X Y Z
SHIP WT.
(LBS)
OPN. WT.
(LBS)
L1 L2 L3 L4
EVAP.
CONN.
(IN.)
VICTAULIC
M1 M2 M3 M4
010B
28.00 21.50 23.40 1085 1095 398 392 149 147 2 279 275 267 263
013B
27.40 21.40 23.90 1170 1190 452 426 150 141 2 315 297 288 271
017B
27.50 21.60 24.00 1280 1300 493 463 167 157 2 344 323 316 297
020B
38.50 21.80 23.90 1505 1525 564 534 209 198 2 502 475 271 257
025B
39.50 19.40 24.00 1610 1635 593 554 239 224 2 531 496 301 282
029B
41.00 22.75 24.20 1800 1830 645 595 291 269 2 583 238 353 326
034B
35.60 23.70 23.50 2270 2315 890 869 259 253 2 779 761 369 361
Table 15, Remote Evaporator, Dimensions and Weights
CENTER OF GRAVITY
(IN.)
LIFTING CORNER WEIGHTS
(LBS)
CONNECTION SIZES (IN. O.D.)
AGZ
REMOTE
EVAP.
X Y Z
SHIP
WT.
(LBS)
OPN.
WT.
(LBS)
L1 L2 L3 L4 SUCTION LIQUID
HOT GAS
BYPASS
010B
27.50 21.70 22.90 1000 1015 369 379 124 128 1.125 0.875 0.625
013B
26.50 21.60 23.40 1065 1090 421 416 115 113 1.625 0.875 0.625
017B
26.60 21.80 23.30 1150 1190 454 449 124 123 1.625 0.875 0.625
020B
38.50 21.90 23.30 1370 1420 501 498 186 185 1.625 0.875 0.625
025B
38.50 19.10 23.30 1390 1445 508 505 189 188 1.625 0.875 0.625
029B
41.00 23.00 23.30 1565 1625 540 538 244 243 1.625 0.875 0.875
034B
34.60 24.00 22.40 1975 2050 753 807 201 215 2.125 0.875 0.875
Table 16, Mounting Weights
MOUNTING CORNER WEIGHTS (LBS.)
AGZ
REMOTE
EVAP
M1 M2 M3 M4
010B
257 264 236 243
013B
290 286 246 243
017B
312 309 266 263
020B
446 443 241 240
025B
453 449 245 243
029B
488 487 296 295
034B
656 703 297 318
