IOMM AGZB1 AGZ 010B through 034B 21
Table 9, Compressor and Condenser Fan Motor Amp Draw, R-22
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line
AGZ
Unit
Size
Volts
No. 1 No. 2
Fan
Motor
(Each)
No. of
Fans
Fan
Motor
(Each)
No. 1 No. 2
208 19.4 19.4 5.8 2 21.4 156 156
230 18.6 18.6 5.8 2 23.7 156 156
460 9.0 9.0 2.8 2 10.7 75 75
010B
575 7.4 7.4 2.5 2 11.0 54 54
208 28.8 28.8 5.8 2 21.4 195 195
230 28.8 28.8 5.8 2 23.7 195 195
460 14.7 14.7 2.8 2 10.7 95 95
013B
575 10.8 10.8 2.5 2 11.0 80 80
208 31.2 31.2 5.8 2 21.4 225 225
230 30.1 30.1 5.8 2 23.7 225 225
460 15.5 15.5 2.8 2 10.7 114 114
017B
575 12.1 12.1 2.5 2 11.0 80 80
208 42.3 42.3 5.8 3 21.4 245 245
230 42.3 42.3 5.8 3 23.7 245 245
460 18.2 18.2 2.8 3 10.7 125 125
020B
575 14.9 14.9 2.5 3 11.0 100 100
208 48.1 48.1 5.8 3 21.4 300 300
230 48.1 48.1 5.8 3 23.7 300 300
460 21.8 21.8 2.8 3 10.7 150 150
025B
575 18.6 18.6 2.5 3 11.0 109 109
208 53.2 53.2 5.8 3 21.4 340 340
230 53.2 53.2 5.8 3 23.7 340 340
460 26.5 26.5 2.8 3 10.7 173 173
029B
575 21.7 21.7 2.5 3 11.0 132 132
208 73.1 73.1 5.8 3 21.4 505 505
230 73.1 73.1 5.8 3 23.7 505 505
460 30.5 30.5 2.8 3 10.7 225 225
034B
575 24.4 24.4 2.5 3 11.0 180 180
See "Electrical Notes" on page
26
.
