IOMM AGZB1 AGZ 010B through 034B 29
Figure 10, AGZ 010 - 017BM Remote Evap. (See page 30 for additional dimensions and weights
Figure 11, AGZ 020BM - 034BM (See page 30 for additional dimensions and weights
.875
CONTROL
ELECTRICAL
KNOCKOUT
NOTE:
L2 & L4 ARE LOCATED ON1.
OPPOSITE SIDE OF UNIT.
ALL WEIGHTS ARE IN POUNDS.2.
R331987401
00
CERTIFIED, 2 FAN, AGZ-B REMOTE
21.18
46.18
X
18.84
9.19
20.79
24.57
5.17
5.06
4.56
8.86
73.80
4.00
MOUNTING HOLES
DIA. 1.00 INCH
QTY. 4
49.06
.875
POWER ENTRY
KNOCKOUT
(OTHER SIDE)
L1, L2L3, L4
HOT GAS
BYPASS
SUCTION
LIQUID
51.00
Z
Y
31.15
MOUNTING
HOLES
7.64
46.42
ACCESS
DOOR
CONTROL BOX
ACCESS DOORS
POWER
ENTRY
ACCESS
PANEL
.875
CONTROL
ELECTRICAL
KNOCKOUT
DIM. A = ACZ025-028 = 24.6"
ACZ033-039 = 33.0"
DIM. B = ACZ025-028 = 40.2"
ACZ033-039 = 48.7"
DIM. C = ACZ025-033 = 18.8"
ACZ039 = 12.6"
DIM. D = ACZ025-033 = 4.5"
ACZ039 = 7.5"
NOTE:
L2 & L4 ARE LOCATED ON1.
OPPOSITE SIDE OF UNIT.
ALL WEIGHTS ARE IN POUNDS.2.
R331987501 CERTIFIED, 3 FAN, AGZ-B REMOTE
84.95
21.18
X
106.23
49.06 49.06
5.17
B
9.19
C
20.79
A
5.06
D
2.67
8.86
.875
POWER ENTRY
KNOCKOUT
(OTHER SIDE)
L1,L2L3,L4
HOT GAS BYPASS
SUCTION
LIQUID
ACZ025-028 =51
ACZ033-039 = 59
Z
Y
7.64
31.10
MOUNTING
HOLES
46.38
CONTROL PANEL
ACCESS DOORS
ACCESS
DOOR
POWER
ENTRY
ACCESS
PANEL
