M5LCY-II_(i) Engineering & Physical Data
27
Engineering Data - M5CMY-ER (3 phase)
MODEL
INDOOR UNIT
M5CMY40ER M5CMY50ER M5CMY62CR
OUTDOOR UNIT
M5LCY40FR M5LCY50FR M5LCY60FR
NOMINAL COOLING CAPACITY
Btu/h
34100 42600 44300
W
10000 12500 13000
NOMINAL HEATING CAPACITY
Btu/h
38200 47700 52800
W
11200 14000 15500
NOMINAL TOTAL INPUT POWER (COOLING)
W
3100 4150 4890
NOMINAL TOTAL INPUT POWER (HEATING)
W
3100 3880 4290
NOMINAL RUNNING CURRENT (COOLING)
A
4.86 6.47 7.54
NOMINAL RUNNING CURRENT (HEATING)
A
5.02 6.06 6.64
EER
W/W
3.23 3.01 2.66
COP
W/W
3.61 3.61 3.61
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR EXV
REFRIGERANT CHARGE kg
4.30
POWER SOURCE V/Ph/Hz
380~415 /3/ 50
REFRIGERANT TYPE
R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTOMATIC LOUVER (UP & DOWN)
OPERATION
WIRED OR WIRELESS REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM
520 / 1100 570 / 1215 732 / 1550
MEDIUM l/s / CFM
464 / 983 511 / 1082 651 / 1320
LOW l/s / CFM
414 / 877 453 / 959 472 / 1000
SOUND PRESSURE LEVEL (H/M/L)
dBA
52 / 47 / 46 52 / 50 / 49 56 / 53 / 46
UNIT DIMENSION HEIGHT X WIDTH X DEPTH
mm
260 X 1538 X 634 260 X 1786 X 634 285 X 1930 X 608
PACKING DIMENSION HEIGHT X WIDTH X DEPTH
mm
330 X 1645 X 724 330 X 1892 X 724 351 X 2016 X 788
UNIT WEIGHT kg
45 65 70
CONDENSATE DRAIN SIZE mm
19.1
FAN
TYPE
SIROCCO
DRIVE
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDEX OF PROTECTION (IP)
N/A
INSULATION GRADE
CLASS B CLASS E
RATED INPUT POWER W
190 240 297
RATED RUNNING CURRENT A
0.90 1.10 1.30
MOTOR OUTPUT W
118 149 80
POLES
4
COIL
TUBE
MATERIAL
INNER GROOVE COPPER PLAIN COPPER
DIAMETER mm
7.00 9.52
FIN
MATERIAL
HYDROPHILIC (RAISE LANCE)
HYDROPHILIC
(SLIT FIN)
FACE AREA m
2
0.32 0.38 0.42
ROW
34
AIR QUALITY FILTER
TYPE
WASHABLE SARANET FILTER
QUANTITY pc
3 2+2 2+3
CASING COLOUR
LIGHT GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM
1553 / 3290 1534 / 3250
SOUND PRESSURE LEVEL dBA
50 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm
1374 x 900 x 320
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm
1529 x 1030 x 421
UNIT WEIGHT kg
100
PIPE
CONNECTION
TYPE
FLARE VALVE
SIZE
LIQUID mm
9.52
GAS mm
15.87
FAN
TYPE
PROPELLER
DRIVE
DIRECT
FAN MOTOR
TYPE
BRUSHLESS DC MOTOR
INDEX OF PROTECTION (IP)
43
INSULATION GRADE
CLASS E
RATED INPUT POWER W
145 141
RATED RUNNING CURRENT A
1.30 1.26
MOTOR OUTPUT W
70
POLES
8
COMPRESSOR
TYPE
SCROLL
OIL TYPE
DAPHNE FVC68D
OIL AMOUNT cm
3
1000
RATED INPUT POWER (COOLING) W
NA
RATED INPUT POWER (HEATING) W
NA
RATED RUNNING CURRENT (COOLING) A
NA
RATED RUNNING CURRENT (HEATING) A
NA
COIL
TUBE
MATERIAL
COPPER
DIAMETER mm
7
FIN
MATERIAL
ALUMINIUM
FACE AREA m
2
1.14
ROW
2
CASING COLOUR
LIGHT GREY
DRAWING NUMBER
000452203R4040 000452203R5050 000452203CY6260
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
All SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
