Engineering Data - M5CCY-CR (3 phase)
MODEL
INDOOR UNIT
M5CCY38CR M5CCY50CR M5CCY60CR
OUTDOOR UNIT
M5LCY40FR M5LCY50FR M5LCY60FR
NOMINAL COOLING CAPACITY
Btu/h
34800 43300 47700
W
10200 12700 14000
NOMINAL HEATING CAPACITY
Btu/h
38200 47700 56200
W
11200 14000 16.5
NOMINAL TOTAL INPUT POWER (COOLING)
W
3320 4270 4970
NOMINAL TOTAL INPUT POWER (HEATING)
W
3260 4280 4970
NOMINAL RUNNING CURRENT (COOLING)
A
5.20 6.54 7.61
NOMINAL RUNNING CURRENT (HEATING)
A
5.12 6.64 7.67
EER
W/W
3.07 2.97 2.82
COP
W/W
3.44 3.27 3.32
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR EXV
REFRIGERANT CHARGE kg
4.30
POWER SOURCE V/Ph/Hz
380~415 /3/ 50
REFRIGERANT TYPE
R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
OPERATION
WIRED MICROCOMPUTER REMOTE CONTROL
AIR FLOW
SUPER HIGH l/s / CFM
604 / 1280 675 / 1430 812 / 1720
HIGH l/s / CFM
547 / 1160 623 / 1320 731 / 1550
MEDIUM l/s / CFM
496 / 1050 580 / 1230 632 / 1340
LOW l/s / CFM
434 / 920 533 / 1130 552 / 1170
EXTERNAL STATIC PRESSURE (SH/H/M/L)
Pa
118 / 96 / 78 / 61 147 / 126 / 109 / 92 147 / 120 / 90 / 69
SOUND PRESSURE LEVEL (SH/H/M/L)
dBA
55 / 51 / 48 / 45 53 / 52 / 50 / 47 55 / 53 / 50 / 47
UNIT DIMENSION HEIGHT X WIDTH X DEPTH
mm
305 X 1302 X 638 378 X 1299 X 541 378 X 1499 X 541
PACKING DIMENSION HEIGHT X WIDTH X DEPTH
mm
355 X 1461 X 727 415 X 1497 X 631 415 X 1701 X 631
UNIT WEIGHT kg
47 50 56
CONDENSATE DRAIN SIZE mm
19.1
FAN
TYPE
SIROCCO
DRIVE
DIRECT
FAN MOTOR
TYPE
1-Phase Fixed Speed
INDEX OF PROTECTION (IP)
IP21
INSULATION GRADE
CLASS B CLASS E
RATED INPUT POWER W
503 515 659
RATED RUNNING CURRENT A
0.93 1.07 1.01
MOTOR OUTPUT W
470 480 600
POLES
4
COIL
TUBE
MATERIAL
INNER GROOVE COPPER
DIAMETER mm
7.00
FIN
MATERIAL
ALUMINIUM (SLIT FIN)
FACE AREA m
2
0.35 0.41 0.48
ROW
3
AIR QUALITY FILTER
TYPE
WASHABLE SARANET FILTER
QUANTITY pc
2
CASING COLOUR
WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM
1553 / 3290 1534 / 3250
SOUND PRESSURE LEVEL dBA
50 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm
1374 x 900 x 320
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm
1529 x 1030 x 421
UNIT WEIGHT kg
100
PIPE
CONNECTION
TYPE
FLARE VALVE
SIZE
LIQUID mm
9.52
GAS mm
15.87
FAN
TYPE
PROPELLER
DRIVE
DIRECT
FAN MOTOR
TYPE
BRUSHLESS DC MOTOR
INDEX OF PROTECTION (IP)
43
INSULATION GRADE
CLASS E
RATED INPUT POWER W
145 141
RATED RUNNING CURRENT A
1.30 1.26
MOTOR OUTPUT W
70
POLES
8
COMPRESSOR
TYPE
SCROLL
OIL TYPE
DAPHNE FVC68D
OIL AMOUNT cm
3
1000
RATED INPUT POWER (COOLING) W
NA
RATED INPUT POWER (HEATING) W
NA
RATED RUNNING CURRENT (COOLING) A
NA
RATED RUNNING CURRENT (HEATING) A
NA
COIL
TUBE
MATERIAL
COPPER
DIAMETER mm
7
FIN
MATERIAL
ALUMINIUM
FACE AREA m
2
1.14
ROW
2
CASING COLOUR
LIGHT GREY
DRAWING NUMBER
000452203Q3840 000452203Q5050 000452203Q6060
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
All SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
