M5LCY-II_(i) Outlines & Dimensions
33
Outdoor Unit
Model: M5LCY 40/50/60FR
AQ AR
AU
P
R
Q
Y
X
Z
HI
G
C
A
AK
AJ
ADAB
AC
APAO
AN
AM AL
AS
AT
F JK
L M
AI
AH
AG AF
AA
AE
NO
S
T
V
W
U
E
D
B
Model
AB CDEFGH I JK LMNOPQRSTUVWX
M5LCY
40/50/60FR
940 1374 30 24 60 89 142 89 19 54 95 423 430 95 54 19 89 145 84 55 55 223 148 13
Y Z AA AB
AC AD AE AF AG AH AI AJ AK AL AM AN AO AP AQ AR AS AT AU
52 67 350 140 620 140 30 320 30 59 43 40 94 117 102 70 45 376 191 70 58 16 16
Drawing number: 70014114086 Note: Dimension in mm
