10. PATELLA
Insert the patella resection guides into the patella clamp.
After carefully releasing the periphery of the patella,
position the resection guides at the appropriate resection
level, with the assistance of the patellar stylus assembled
in one slot of the resection guide. The stylus should be in
contact with the top of the patella dome allowing for a 10
mm fixed cut.
Then close the clamp handle until contact between the
resection guides and the patella bone is made and lock the
clamp with the button provided.
Locking button
64.
CAUTION
Check that at least 13 mm of bone remains after resection.
Perform the patellar resection through the slots of the
resection guides.
OPTION
The patella size can be assessed using dedicated
templates.
Open the patellar clamp, remove the two resection guides
and position the spike jaw and drilling guide.
65.
CAUTION
To correctly position the patellar component, its single peg
has to be positioned on the lateral facet of the patella and
the other two pegs on the medial facet once the patella is
in place i.e. not luxated.
Apply the drilling guide on the resected surface of the
patella and drill the three holes using the patellar pegs drill.
Pressurize the trial resurfacing patella of the appropriate
size, reduce the patella and test the knee through its full
range of motion.
