Medacta GMK Sphere - Cutting Block Compatibility

GMK Sphere Calipered Kinematic Alignment Surgical Technique
32
14.2 PROXIMAL TIBIAL RESECTION
The compatibility between the the metal slotted tibial cutting and the MIS metal distal cutting guide is highlighted in the table
below.
Metal slotted tibial cutting guide
02.07.10.4542/4543
Reference line
Metal slotted MIS tibial cutting guide
02.07.10.0290/0291
Reference line
71.
Tibial cutting block holes (right knee)

Parallel positioning holes

Oblique fixation holes

Tibial stylus holes
Sawblade slot
15. ANNEX 3 4IN1 CUTTING BLOCK COMPATIBILITY
It is also possible to use 4in1 built-in pins to perform anterior cut, posterior cut and chamfers.
72.

Oblique fixation pins
Built-in pins
A modular femoral sizer is available to position the 4in1 cutting block.
