Medacta GMK Sphere - Annex 1 Unslotted Guide Compatibility; Proximal Tibial Resection

GMK Sphere Calipered Kinematic Alignment Surgical Technique
30
13. ANNEX 1 UNSLOTTED GUIDE COMPATIBILITY
13.1 DISTAL FEMORAL RESECTION
In the table below is highlighted the compatibility between the metal slotted distal cutting guides and the metal unslotted
distal cutting guides.
Metal slotted distal cutting
guide 02.07.10.4574
Metal unslotted distal cutting
guide 02.07.10.0127
Metal unslotted MIS distal
cutting guide 2.618
67.

Compatible holes
The unslotted cutting guide is compatible only with the unslotted distal cut positioner (ref. 02.07.10.0185).
13.2 PROXIMAL TIBIAL RESECTION
The compatibility between the unslotted metal distal cutting guides is highlighted in the table below.
Metal slotted tibial
cutting guide 02.07.10.4542/4543
Metal unslotted MIS
recut guide 02.07.10.0102
Metal unslotted tibial
cutting guide 02.07.10.0111/0113
Metal unslotted MIS
recut guide 02.07.10.0103
68.

Compatible holes
