Medacta GMK Sphere - KA Instrument Complement

GMK Sphere Calipered Kinematic Alignment Surgical Technique
40
17. KA INSTRUMENT COMPLEMENT
1
2
3
8
7
4
9
1110
12
13
5
6
N. Reference Description Q.ty
1 02.12.10.0721
Distal Cut Reference
Block Unworn-Unworn
1
2 02.12.10.0722
Distal Cut Reference
Block Worn-Unworn
1
3 02.12.10.0723
Distal Cut Reference
Block Unworn-Worn
1
4 02.12.10.0724
Distal Cut Reference
Block Worn-Worn
1
5 02.12.10.0725
2° Valgus correction
cutting guide
1
6 02.12.10.0726
2° Varus correction
cutting guide
1
7 02.12.10.0727
+2mm correction
cutting guide
1
8 02.12.10.0728 Bone resection caliper 1
9 02.12.10.0729 Tibia-femur offset caliper 1
10 02.12.10.0730 +1mm Washer for 4in1 2
11 02.12.10.0731 +2mm Washer for 4in1 2
12 02.12.10.0732 IM Rod 1
13 02.12.10.8214
GMK Sphere Kinematic
Alignment - Tray
1
