MEGADYNE MEGA POWER - Controller Board Replacement

41
Equipment required:
• Phillips screwdriver
Step 1 – Remove the ESU Cover and Chassis Cover
Turn off the generator, Disconnect the power cord from the wall receptacle
Remove the five (5) screws that secure the cover (item A) to the chassis. Pull the cover
off of the chassis by pulling the ESU cover horizontally toward the rear of the ESU.
A
Screw
Screw
Screw
Screw
Screw
