Remove the ESU Cover and Chassis Cover , continued
Remove the chassis cover (item B):
Remove the four (4) screws that secure the Chassis Cover to the Chassis.
Lift the front of the Chassis Cover and remove both wire harness connecters from the
front panel which connect to the Chassis Cover.
Note – Step 1 will be required before proceeding with any of the following steps.
Screw
Screw
Screw
Screw
To Next Page
