Megger BITE5 User Manual

Electrical specifications
Internal impedance
Range Resolution Accuracy
3 mΩ 1 μΩ +/- 1 % of reading +/- 10 digits
30 mΩ 10 μΩ +/- 0.8 % of reading +/- 10 digits
300 mΩ 100 μΩ
3 Ω 1 mΩ
30 Ω 10 mΩ
300 Ω 100 mΩ
Voltage DC/AC
Range Resolution Accuracy
5 V DC 0.00 1 V +/- 0.5 % of reading +/- 5 digits
50 V DC 0.0 1 V
500 V DC 0.1 V
1000 V DC 1 V
5 V AC .001 V +/- 0.75 % of reading +/- 5 digits
(40 Hz – 100 Hz)
50 V AC 0.01 V
500 V AC 0.1 V
600 V AC 1 V
Current DC/AC
Range Resolution Accuracy
4 A DC 0.001 A +/- 0.5 % of reading +/- 5 digits +
(CT Tolerance)
40 A DC 0.01 A
400 A DC 0.1 A
1000 A DC 1 A
4 A AC 0.001 A +/- 0.75 % of reading +/-10 digits +
(CT Tolerance)
40 A AC 0.01 A
400 A AC 0.1 A
1000 A AC 1 A
Temperature
Range Resolution Accuracy
10 °C ~ 100 °C
50 °F ~ 212 °F 0.1 °C +/-1 °C +/- 2 digits
Ripple Voltage
Range Resolution Accuracy
0 - 5 V 0.001 V +/- 0.5 % of reading +/- 10 digits (40
Hz – 10 KHz)
Accuracy specifications assume an ambient temperature of 18 °C to 28 °C, stable within +/-1 °C and a warm-up time
of 30 minutes.
www.megger.com
BITE5
10
