Connections and controls
Connections
Mini USB input and micro SD card slot
Current probe input
Voltage lead inputs
Impedance probe inputs
ON/OFF switch
DC power adapter input
Controls
Lock and unlock screen
Ohmic testing
VA testing
Data and string records
Recorded data charts
Instrument configuration
Zero adjustment
For accurate ohmic measurements, it is recommended that a zero adjust is performed when changing probes.
To perform a zero adjust, use the included zero bar.
When performing a zero adjustment, place the source pin on the outer copper surface of the zero bar and place the
sensor pin in one of the holes of the zero adjust bar.
