Megger BITE5 User Manual

Viewing a record
The BITE5 allows the viewing of various recorded values or records. These records include the following:
Meter Ω - These will be the individual recorded impedance measurements that were made with the BITE5. These
recorded values are not associated with any battery strings.
String Ω - These will be the recorded values of individual impedance tests made on strings.
D Ω String - These will be the recorded values of individual impedance measurements made during a discharge test on
a string.
Meter VA - These will be the individual recorded voltage and current measurements that were made with the BITE5.
These recorded value are not associated with any battery strings.
String VA - These will be the recorded values of voltage and current measurements made on strings.
D VA String - These will be the recorded values of the voltage and current measurements made during a discharge test
on a string.
Viewing Meter Ω records
On the BITE5 select the record ICON.
Select “Meter Ω”.
www.megger.com
BITE5
44
Viewing a record
