Automatic saving of values
Select “Auto Hold” and the BITE5 will automatically save any measurement with a date and time stamp.
Performing a discharge test
The BITE5 can be used in conjunction with the Megger Torkel discharge tester. Program the Torkel for the desired
discharge test. Place the Torkel across the battery string and start the discharge test. The BITE5 can then be used to take
manual measurements of the cell voltage throughout the discharge process.
In this mode, the unit will record the DC voltage of each cell as well as the DC current through the string if the optional
Hall Effect CT is used.
Operation:
Connect the voltage leads to voltage inputs of the BITE5.
If measuring current, then plug the CT into the BITE5 CT input.
Select the desired current range on the CT.
www.megger.com
BITE5
27
Performing a discharge test
