AVTMTTR330 Rev 3 March 2010
23
5
Operation
Power up
Proceed only after reading and fully reading and understanding Sections 2, 3, and
4, with particular attention on the safety related precautions.
Once all safety precautions are taken, and all circuit connections are made, then
the user may safely turn the ON/OFF switch to the ON position and operate
the test instrument as described herein.
F
EMERGENCY SHUTDOWN
For Emergency shutdown, Push red EMERGENCY OFF
button or toggle On/OFF switch to OFF.
On power up, a beep sounds, the test set performs a self-test check, and all
hardware and software variables are initialized.
Navigating the screen
HOME Screen Action Icons
Select HOME key to display Action Icons.
Use ENTER key (in center) to select highlighted action
Use Arrows keys to highlight desired action
To Next Page
