AVTMTTR330 Rev 3 March 2010
39
7
Replacement Parts List and Optional Accessories
Table 7-1. Replacement Parts List
Item Cat. No.
Three-phase Transformer Turns Ratio Test Set
120 V ac ±10%, single phase, 50 ±2 Hz or 60 ±2 Hz, 100 VA
230 V ac ±10%, single phase, 50 ±2 Hz or 60 ±2 Hz, 100 VA
TTR330
TTR330-47
Fuse Kit
For TTR330 35026-5
For TTR330-47 35026-2
Included Accessories
Canvas carrying bag for test leads 30915-211
Power supply cord, 8 ft (2.5 m) 17032-4
Ground lead, 15 ft (4.6 m) 4702-7
Test Leads
For 3-phase connections, shielded, clamp-end terminated
H winding, 10 ft (3.1 m)
X winding, 10 ft (3.1 m)
30915-509
30915-508
Extensions, shielded
H winding, 33 ft (10 m)
X winding, 33 ft (10 m)
30915-501
30915-500
Hand-held switch assembly for LTC remote control testing 30915-220
PowerDB Lite Software
Ethernet cable for connecting to a PC 36798
Bushing clamps (6 pcs) MC7144
Transformer Vector Voltage Diagrams
ANSI Standards
IEC Standards
AS (Australian) Standards
35298
35299
35300
