Megger Three-Phase TTR User Manual

Operation
AVTMTTR330 Rev 3 March 2010
25
3-Phase QUICK test, example
Figure 5-2. Three Phase QUICK test Screen
Select Recall to open test from memory (either internal or USB memory).
Figure 5-3. File Manager -Recall Test
Use Navigation keys
Arrows/ENTER)
to select winding
configuration,
then Press TEST
Use Zone Key to move
cursor to various zones
on display
