Megmeet MV300 Series User Manual

14
Note: For 75kWG drive or above, DC reactor is included in its standard configuration. The weight of DC
reactor is not included in the gross weight of the Table 1-4 and Table 1-5. Outline and dimensions of DC
reactor are shown below. For the drive of 355kWG/355kWP and above, DC reactor is included in its standard
configuration.
Diameter of terminal
Enlarged view of terminal
Mounting
hole
Mounting
hole
Fig. 1-6 Dimensions of DC reactor
Table 1-6 Mechanical Parameters of DC Reactor
Applicable
drive（kW）
Model of DC reactor
Recommended
size of copper
（mm
2
）
Size（mm）
Gross
weight
（kg）
A B C D E F G H I J
Diameter
of
terminal
75G DCL-0160-UIDH-7908
60 160 100 98 130 95 65 9 215
/
20
Ф8 14.5
90G/90P DCL-0180-UIDH-7908 Ф10 16
110G/110P DCL-0250-UIDH-7908 100 210 176 115 150 125 84 11 255 30 Ф12 25.5
132G/132P JSY-3674
150
200 170
135 171
120
85
10 260 280
30 Ф12
28
160G/160P JSY-3449 210 180 130 12 280 320 32
200G/200P
JSY-3066-1
200
220 190
135 171 150 90
12 315 340 40 Ф15
40
220G/220P 250
280G/280P
JSY-3067-1 325 145 181 160 95 45
315G/315P
 Note
1．Columns B and C in Table 1-6 are the sizes of mounting holes of DC reactor.
