Megmeet SPS-NE Series User Manual

14
Type
Mark
Name
Function description
Note
Multi-func
tion input
terminals
DI1
Digital input
terminal 1
FWD
ON: Forward running
OFF: Stop
Optocoupler isolation input
Input impedance: 3.9 K
Maximum input frequency: 200 Hz
Input voltage range: 20 to 30 V
DI2
Digital input
terminal 2
Speed/Position switchover
terminal
OFF: Speed mode
ON: Position mode
DI3
Digital input
terminal 3
Spindle/Positioning homing
terminal
ON: Spindle homing
DI4
Digital input
terminal 4
Tapping enable
ON: Switched to the tapping
mode
DI5
Digital input
terminal 5
Emergency stop
ON: Emergency stop
DI6
Digital input
terminal 6
Spindle swing
ON: Spindle swing
DI7
Digital input
terminal 7
Reaming enable
ON: Reaming enabled
DI8
Digital input
terminal 8
Fault rest
ON: Fault reset

Megmeet SPS-NE Series Specifications

General

Brand	Megmeet
Model	SPS-NE Series
Category	Servo Drives
Language	English
