Megmeet SPS-NE Series User Manual

18
5
EXC+
Encoder EXC+ signal
6
EXC-
Encoder EXC- signal
10
L+
Motor temperature detection +
20
L-
Motor temperature detection -
Housing
Shield
Shield
Absolute Encoder (in development)
Pin
Signal name
Description
Pin
Signal name
Description
1
COS+
COS+ signal
11
DAT+
Differential communication
data signal +
2
COS-
COS- signal
12
DAT-
Differential communication
data signal -
3
SIN+
SIN+ signal
13
CLK+
Differential communication
clock signal + (only
applicable for Endat
protocol)
4
SIN-
SIN- signal
14
CLK-
Differential communication
clock signal - (only
applicable for Endat
protocol)
7
+5V
5 V power output
Other
NC
Not connected
8
GND
Ground
20
L-
Motor temperature
detection -
10
L+
Motor temperature
detection +
Housing
Shield
Shield
 Serial communication interface definition (CN1)
Reserved.
