Megmeet SPS-NE Series User Manual

17
6
Z-
Encoder Z- signal
16
W-
Encoder W- signal
7
+5V
5 V power output
Other
NC
Not connected
8
GND
Ground
20
L-
Motor temperature detection -
10
L+
Motor temperature
detection +
Housing
Shield
Shield
Sin/Cos Encoder
Pin
Signal name
Description
Pin
Signal name
Description
1
A+
Encoder A+ signal
11
C+
Encoder C+ signal
2
A-
Encoder A- signal
12
C-
Encoder C- signal
3
B+
Encoder B+ signal
13
D+
Encoder D+ signal
4
B-
Encoder B- signal
14
D-
Encoder D- signal
5
Z+
Encoder Z+ signal
Other
NC
Not connected
6
Z-
Encoder Z- signal
20
L-
Motor temperature
detection -
7
+5V
5 V power output
Housing
Shield
Shield
8
GND
Ground
10
L+
Motor temperature
detection +
Resolver (in development)
1
COS+
Encoder COS+ signal
2
COS-
Encoder COS- signal
3
SIN+
Encoder SIN+ signal
4
SIN-
Encoder SIN- signal
