Megmeet SPS-NE Series - Objects of Drive Parameters

82
 Objects of drive parameters
The indexes for objects of SPS-NE drive parameters are listed in the following table:
Parameter
group
Index
Sub-index
Note
P00
2000h
01h to max. number of group
parameters
Index of drive parameter=(2000h+function group);
Sub-index of drive parameter=(actual function code
No. in the group+1).
[Example]
P00.00 as the first parameter in the P00 group:
Index=2000h, sub-index=01h;
P00.10 as the eleventh parameter in the P00 group:
Index=2000h, sub-index=0Bh;
P30.10 as the eleventh parameter in the P30 group:
Index=201Eh, sub-index=0Bh.
P01
2001h
01h to max. number of group
parameters
……
P98
2062h
01h to max. number of group
parameters
For details about parameter groups, index information, parameter types, parameter reading/writing and the like,
refer to “Parameter List”.
