Megmeet SPS-NE Series User Manual

21
Function
code
Name
Value range
Default value
Change
P02.05
Digital setting of main
frequency reference
P02.17 to P02.16
50.00
○
P02.15
Maximum output
frequency
MAX[50.00, upper limit frequency P02.16]
to 3000.00 Hz
50.00
×
P02.16
Upper limit frequency
P02.17 to P02.15
50.00
○
P02.17
Lower limit frequency
0.00 to P02.16
0.00
○
(1) P02.00 shall be set by the user based on the onsite conditions. For example, for “asynchronous motor+encoder”,
P02.00 shall be set to “01”;
(2) P02.04 can be used to choose the source of main frequency reference in speed control. P02.01 is valid only when
P02.02=1 (terminal control);
(3) Under bus control, both command source and frequency source are set by the bus, and function codes are
ineffective.
2. Motor parameters
Function
code
Name
Value range
Default value
Change
P03.00
Motor rated power
0.4 to 999.9 kW
Model-dependent
×
P03.01
Motor rated voltage
0 to rated voltage of servo drive (P98.04)
Model-dependent
×
P03.02
Motor rated current
0.1 to 999.9 A
Model-dependent
×
P03.03
Motor rated frequency
1.00 to 3000.00 Hz
Model-dependent
×
P03.04
Motor rated speed
0 to 60000 rpm
Model-dependent
×
P03.24
Parameter auto-tuning
1: Motor static auto-tuning
2: Motor rotation auto-tuning
0
×
P03.26
Encoder installation
initial angle
0 to FFFFH
0
×
