4 Description of the device
17
Symbols in the status bar Meaning
Energy-saving
mode
Indicates whether the steam sterilizer is currently in energy-saving
mode
Service area Indicates whether a service technician is logged-in to the service area
CF card status Indicates whether a CF card has been inserted and whether a reading
or writing action is in process
Symbol in the menu bar Meaning
Program/tests Lists all sterilization programmes and tests e.g. Vacuum test, Bowie &
Dick test etc.
Log output Here you can display the entire log list or the list of logs from a
restricted time e.g. the day, month etc. You can also delete specific log
types and logs.
Settings Here you can perform various settings such as date and time,
brightness etc. It also enables one-time setting of the standard logging
settings regarding log output.
Info/status window Displays information regarding the software version and device data
e.g. total number of batches, maintenance counter, log settings, log
memory and further technical values.
Service area Only for service technicians.
Help menu Depending on the window selected and the operating situation, gives
information regarding operation or the function of the window currently
selected.
Symbols in the action bar Meaning
Door open Opens the door of the steam sterilizer
Back Navigates to the previous window
Forwards Navigates to the next window
Cancel / return
without saving
Navigates to the superordinate menu, leaves the window without
saving
Zoom (+) Displays further details such as further values after a completed
program
Start time pre-
selection
Navigates to the menu Start time pre-selection
Delete Deletes logs from the internal log memory/deletes the log printer or
label printer stored as standard
Search Searches for label printer(s)/log printer(s)
Skip Navigates to the next window without entry of the required data
