INTRODUCTION
Main components
1. Front control card.
2. Pumping control card.
3. Cylinder air pressure regulator.
4. Cylinder air pressure gauge.
5. Warning light (optional).
6. Cylinder.
7. Cylindrical hopper (adhesive load).
8. Pressure relief valve (for non-moisture curing
adhesives).
9. Purge valve.
10. Filter pump.
11. Hose- applicator hydraulic connection.
12. Air supply input.
13. Pump system connection switch (optional)
14. Hose- applicator electrical connection.
15. General power switch and power supply
5
6
7
3
4
1
2
15
14
12
13
11
8
9 10
