9-5
SPARE PART LIST MA-5081-E B4 NS ADHESIVE MELTER MANUAL
C. MOTOR- PUMP UNIT
Nº Ref. Description
1 150026110 2cc/rev gear pump
1.1 150090410 Pump seating o-rings
1.2 R0007984 Gasket system in the shaft
2 150026090 Motor coupling
3 150026080 Geared motor ratio 43,39:1
4 150026100 Geared motor support
24
1
1.1 1.2
3
