TECHNICAL CHARACTERISTICS
6-1
MA-5081-E B4 NS ADHESIVE MELTER MANUAL
6. TECHNICAL CHARACTERISTICS
General
Format and type of adhesive
Maximum viscosity of adhesive
Maximum pump flow rate (*)
Maximum melting rate (*)
Pressure applied on the block
Tank volume
Maximum melting - intermittent and continuous
Gear motor
Pump
Pump rotation speed
Maximum working pressure
Power applied to melter
Total equipment output
External functions
Electrical requirements
Room temperature
Number of outputs
Temperature range
Temperature control
Dimensions
Weight
(*) Under normal conditions
EVA/PUR block 2 Kg-Ø128 mm - height 165 mm
up to 45,000 cps
between 1,2 and 15,6 Kg/hr with 2 cc/rev pump
5 Kg/h
6 bar max. (adjustable)
0.45 litres
Depends on the adhesive viscosity and the length of time the
block is in the lower tank
three-phase 179 W two-pole forced ventilation
2 cc/rev
0-100 rpm (recommended 10-80 rpm continuously)
80 bar max. (1160 psi)
mechanical or pneumatic bypass valve (adjustable)
2100 W (2x750 W at grill + 2x300 W at base)
3680 W_16 A
Temperature output ok
External standby
Starting up the motor
Motor speed set point reference
Failures output in pump control card
LN~ 230 V 50 Hz + PE/ 16A
0 to 40°C
2
40 to 160°C (100 to 320°F)
RTD ±0.5°C (±1°F) Pt100 and Ni120
see diagram on following page
60 kg without load (approx)
