3 Appliance description
3.1 Legend for Figure A
Fig. number Explanation
1 Drip tray with cup plate and coffee grounds container (internal)
2 "Perfect Cappuccino" milk frother
3 Water tank
4
Button for coffee strength
5
Button for steam dispensing
6 Valve switch for steam and hot water dispensing
7 Display
8 Two-chamber bean container „Bean Select“
9 Tilt lever for "Bean Select" bean container
10 Ground coffee chute with lid
11
ON /OFF button
12 Coffee quantity regulator
13
Button for one-cup dispensing
14
Button for two-cup dispensing
15 Height-adjustable outlet
16
Water level indicator oat for the
drip tray
3.2 Legend for Figure B
Fig. number Explanation
17 Power cable
18 Brewing unit and identication label (behind the cover)
19 Grinding neness adjustment
20 Power switch
