Rev. 1.712 Mellanox Technologies
*The same connector is used for the I²C and the console interfaces.
1.4 Features
For a full feature list, please refer to the systems’ product briefs:
http://www.mellanox.com/related-docs/prod_ib_switch_systems/pb_sb7700.pdf
http://www.mellanox.com/related-docs/prod_ib_switch_systems/pb_sb7790.pdf
http://www.mellanox.com/related-docs/prod_ib_switch_systems/pb_sb7800.pdf
http://www.mellanox.com/related-docs/prod_ib_switch_systems/pb_sb7890.pdf
http://www.mellanox.com/related-docs/prod_ib_switch_systems/pb_sb7780.pdf
1.5 Certifications
The list of certifications (such as EMC, Safety and others) per system for different regions of the
world is located on the Mellanox website at:
http://www.mellanox.com/page/environmental_compliance
1.6 Ordering Information
the following table lists ordering information for the available systems. Please pay attention to
the airflow direction when ordering your system. For more details, see
“Air Flow” on page 15.
SB7800 Rear Rear (1
port)
Rear Rear Yes Yes
SB7890 NA NA Rear NA Yes Yes
SB7780 Rear Rear (2
ports)
Rear Rear Yes Yes
Table 5 - Ordering Part Numbers (OPNs)
System
Model
OPN Description
SB7700 MSB7700-
ES2F
Switch-IB™ based EDR InfiniBand 1U Switch, 36 QSFP28 ports, 2
Power Supplies (AC), x86 dual core, standard depth, P2C airflow,
Rail Kit, RoHS6
MSB7700-
ES2R
Switch-IB™ based EDR InfiniBand 1U Switch, 36 QSFP28 ports, 2
Power Supplies (AC), x86 dual core, standard depth, C2P airflow,
Rail Kit, RoHS6
MSB7700-
EB2F
Switch-IB™ based EDR InfiniBand 1U Switch, 36 QSFP28 ports, 2
Power Supplies (AC), x86 dual core, short depth, P2C airflow, Rail
Kit, RoHS6
Table 4 - Management Interfaces and FRUs
System
Model
USB MGT I²C* Console*
Replaceable
PSU
Replaceable
Fan
