Rev. 1.723 Mellanox Technologies
2.4.2 19” Systems Mounting- Telescopic Rail-Kit
There are two installation kit options: standard and short. Standard depth systems should be
mounted using the standard rail kit; short systems can be mounted using either of the rail kits.
The following parts are included in the rail kit rack (see Figure 12):
• 1x Right inner rail (A)
• 1x Left inner rail (B)
• 2x Outer rails (C)
• 2x Outer rails (D)
• 10x M6 Standard cage nuts¹ ² and 10x M6 Standard pan-head Phillips screws¹ (E)
• 2x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with around patch (F)
¹ Other threads are available by special order: M5, 10-32, 12-24
² G-type cage-nut is available by special order.
Note: the Telescopic Rail-Kit is not included in the system’s package, and can be pur-
chased separately.
Table 8 - Installation Kit
Kit OPN Rack Size Rack Depth Range
MTEF-KIT-B Short 17"-24"
MTEF-KIT-S Standard (long) 24"-38"
The rails must be separated prior to the installation procedure. See Figure 13.
