Installation
Rev. 1.7
18Mellanox Technologies
2.4 Mounting Options
By default, the system is sold with the Static Rail-kit described in Section 2.4.1. A Telescopic
rail-kit can be purchased separately. For the Telescopic Rail-kit installation instructions, see Sec-
tion 2.4.2.
2.4.1 19” Systems Mounting - Static Rail-Kit
The following parts are included in the Static Rail kit (see Figure 6):
• 2x Rack mount rails (A)
• 2x Rack mount brackets (B)
• 2x Rack mount blades (C)
• 8x M6 Standard cage nuts and 8x M6 Standard pan-head Phillips screws (D)
• 4x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with around patch (E)
At least two people are required to safely mount the system in the rack.
Table 7 - Installation Kit
Kit OPN Rack Size and Rack Depth Range
MTEF-KIT-A Short (17”-24”) or Standard (24”-34”)
