Mellanox Technologies Spectrum SN2410 - Figure 26: Pulling the Unit Outwards; Figure 27: Locking Mechanism

Installation
Rev 2.2
37Mellanox Technologies
Figure 26: Pulling the Unit Outwards
Step 4. Press on the locking spring (appears in red in Figure 27) on both sides simultaneously, and
continue pulling the unit towards you until it is fully removed.
Figure 27: Locking Mechanism
