3.2.1.1 System Status LED
Figure 62: System Status LEDs - Front and Rear Sides in SN2700
Figure 63: System Status LEDs - Front Side in SN2740
b
Bad Port LED Lights up when a symbol error is detected on
one of the ports.
Off
Unit Identifier LED Lights up on command through the CLI. Off or blue when
identifying a port
a. There are two PSU LEDs in SN2100/SN2010.
b. This LED does not exist in SN2740.
Table 15 - LEDs Symbols
Symbol Name Description
Normal
Conditions
Both of these LEDs in the red
ovals show the system’s status.
The LED in the red oval shows the system’s status.
