Installation
Rev 2.2
43Mellanox Technologies
The following parts are included in the rail kit (see Figure 34):
• 1 metal frame for two systems (A)
• 2 system mounting blades with 8 screw holes - the kit contains enough rails to install 2
systems (B)
• 2 system mounting blades with 7 screw holes - the kit contains enough rails to install 2
systems (C)
• 2 blank (installed) covers (D)
• 30 flat head 4-40 screws - the kit contains enough screws to install 2 systems (E)
• 2 frame rail slides (F)
• 10 (+2 spare units) M6 pan head screws (G)
• 10 (+2 spare units) M6 spring washers (H)
• 10 (+2 spare units) M6 spring steel cage nuts (I)
• 6 (+2 spare units) cable-ties (J)
Table 10 - Installation Kit
Kit OPN Rack Size and Rack Depth Range
MTEF-KIT-D Rack installation kit for SN2100/SN2010 series short depth 1U switches,
allows installation of one or two switches side-by-side into standard depth
racks
