2 MEND Professional Device and Accessories
2.1 Top Panel and Keypad
Figure 1 Top Panel
① Display Area: Menu selection, protocol information, running information and
status, etc. are displayed on LCD screen.
② Channel Status Indication: LED CH1 and CH2 indicate if the output current can
reach their peak current value in the protocol for channel 1 and channel 2,
respectively. If the LED is flashing or ON, check the connection of the electrode to
the body.
③ Protocol Running Control:
• Key START/ON to turn on the unit, or to start the selected protocol.
• Key PAUSE to pause the running of the current protocol. Use key START to
resume the treatment.
