Mercury 175 EFI

CHARGING & STARTING SYSTEM
90-883728 JULY 2001 Page 2B-43
Starter Removal (Solenoid Driven Bendix)
CAUTION
Disconnect battery leads from battery before removing starter.
1. Disconnect battery cables from battery.
2. Disconnect wires from starter solenoid terminals.
3. Remove starter trunion mounting bolts and remove starter from engine.
58428
b
b
a
a-Starter Solenoid
b-Mounting Bolts
