IGNITION
90-883728 JULY 2001 Page 2A-33
Ignition Component Removal and Installation
Flywheel Removal
1. Remove flywheel cover off engine.
2. Remove alternator belt.
3. While holding flywheel with Flywheel Holder (91-52344), remove flywheel nut and
washer.
a
b
58777
a-Flywheel Holder (91-52344)
b-Flywheel
4. Install Flywheel Puller (91-849154T1) into flywheel.
CAUTION
Do not hammer on end of puller center bolt to remove flywheel, or damage may
result to crankshaft or bearings. Do not use heat to aid flywheel removal as fly-
wheel and electrical components under flywheel may be damaged.
b
a
58775
a-Flywheel
b-Flywheel Puller (91-849154T1)
