Mercury 175 EFI

FUEL INJECTION
90-883728 JULY 2001 Page 3B-9
Vapor Separator Components
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
– 1 VAPOR SEPARATOR ASSEMBLY
1 1 COVER KIT
2 1 FITTING - STRAIGHT
3 1 FITTING - STRAIGHT
4 2 ELBOW
5 1 FITTING - STRAIGHT
6 1 O-RING
7 1 VALVE
8 1 CAP
9 1 CAP
10 1 PLUG
11 1 SEAL
12 1 GASKET
13 1 PRESSURE REGULATOR KIT
14 1 O-RING KIT
15 1 WASHER - RUBBER
16 2 SCREW 22 2.5
17 1 SCREW 22 2.5
18 1 GROUND WIRE
19 7 SCREW 30 3.5
20 1 FLOAT KIT
21 1 FLOAT PIN
22 1 INLET VALVE
23 1 SCREW 40 4.5
24 1 FUEL FILTER
25 1 PROBE
26 1 FUEL BAFFLE
27 3 SCREW 40 4.5
28 1 FUEL PUMP KIT
29 1 SLEEVE
30 1 BOWL KIT
31 1 SEAL
32 1 PLUG KIT
33 1 O-RING
34 3 SCREW (M8 x 30) 15 20
35 3 BUSHING
36 3 GROMMET
