FUEL INJECTION
Page 3B-26 90-883728 JULY 2001
3. Remove 3 bolts securing vapor separator assembly to manifold.
58801
a
a
a
a-Bolts
4. Tilt vapor separator assembly out from manifold and remove 9 screws securing cover.
5. Remove vapor separator tank from cover.
6. Pull downward to remove filter from fuel pump.
58869
a
a-Inlet Filter
7. Inspect filter for debris or damage.
Results: If filter is clogged with debris, clean filter with solvent and compressed air or replace filter. Reas-
semble vapor separator to manifold and recheck fuel pressure. If pressure is still below 41 psi (283
kPa), perform fuel Pressure Regulator Test.
