Mercury 175 EFI

POWERHEAD
90-883728 JULY 2001 Page 4A-7
Cylinder Block Assembly
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1
1 CYLINDER BLOCK (150)
1
1 CYLINDER BLOCK (175/200)
2 6 STUD–POWERHEAD (1-3/4 IN.)
3
2 STUD–POWERHEAD (5-1/2 IN.)
3
2 STUD–POWERHEAD (6-3/4 IN.)
4 2 DOWEL PIN–LOCATING
5 2 DOWEL PIN (BEARING RACE)
6 1 COVER–STARTER MOTOR (UPPER)
7 2 SCREW (1-1/2 IN.) (HEX FLANGE) 17.5 23.5
8 1 COVER (LOWER)
9 2 SCREW (2 IN.)(HEX HEAD FLANGE) 17.5 23.5
10 1 ELBOW
11 8 SCREW (3/8-16 x 3-1/4 IN.) 38 51.5
12 6 SCREW (0.312-18 x 1-1/4 IN.) 15 20.3
13 1 CAP
14 1 ADJUSTING SCREW (1/4-20 1-3/4)
15 1 JAM NUT
16 1 PIN
17 1 UPPER END CAP ASSEMBLY
18 1 O-RING
19 1 ROLLER BEARING
20 1 BEARING RACE
21 1 OIL SEAL
22 4 SCREW (5/16-18 x 1 IN.) 150 17.0
23 1 LOWER END CAP
24 1 O-RING (3-1/4 IN. I.D.)
25 2 OIL SEAL
26 4 SCREW (1/4-20 x 3/4) 80 9
27 4 LOCKWASHER
28 1 SCREW (M8 x 14)
29 1 BATTERY CABLE (NEGATIVE)
30 1 BRACKET
31 1 TPS LEVER
32 3 SCREW (M6 x 25) 70 8
33 3 BUSHING
34 3 WASHER
35 3 GROMMET
36 1 THROTTLE POSITION SENSOR
37 1 TPS COVER
38 3 SCREW (10-32 x 2) 15 1.7
39 1 THROTTLE LINK
40 1 J-CLAMP
41 1 SCREW (M6 x 16)
