POWERHEAD
Page 4A-40 90-883728 JULY 2001
Inspect crankshaft ball bearing as outlined in “Cleaning and Inspection,” following.
IMPORTANT: DO NOT remove crankshaft ball bearing, unless replacement is re-
quired.
29. Remove lower ball bearing from crankshaft as follows:
a. Remove retaining ring using a pair of snap ring pliers.
51854
a
b
c
a-Crankshaft Ball Bearing
b-Pliers
c-Retaining Ring
b. Press crankshaft out of lower ball bearing as shown.
51081
a
b
c
d
a-Press
b-Powerhead Stand (91-812549T)
c-Crankshaft Ball Bearing
d-Universal Puller Plate (91-37241)
To Next Page
