Mercury 175 EFI

POWERHEAD
90-883728 JULY 2001 Page 4A-71
Throttle Lever and Shift Shaft
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 THROTTLE CONTROL LEVER
2 1 SCREW (0.375-16 x 1-3/4 IN.)
3 1 BUSHING
4 1 SPACER
5 1 SCREW (2-1/8 IN.)
6 1 NUT (1/4-20)
7 1 CAP
8 1 INSERT
9 1 WASHER 35 4.0
10 1 NUT
11 1 CAM
12 1 BUSHING
13 1 SCREW (M8 x 40)
14 1 SWIVEL BUSHING
15 1 BEARING
16 1 LINK
17 1 ROLLER
18 1 THROTTLE ROLLER
19 1 SCREW (M5 x 16)
20 1 WASHER
21 1 STAR WASHER
22 1 ANCHOR BRACKET
23 1 LATCH
24 1 SCREW-DRIVE
25 1 CAP
26 1 WEAR PLATE
27 1 LATCH
28 1 WASHER
29 1 NUT
Tighten and back off
1/4 turn
30 3 SCREW (0.312-18 x 7/8) 20 27
31 1 GUIDE BLOCK
32 1 SPRING
33 1 LINK ROD
34
1 SHIFT ASSEMBLY (LONG)
34
1 SHIFT ASSEMBLY (X-LONG)
35 1 ROLL PIN
36 1 SHIFT SHAFT LEVER-UPPER
37 1 BUSHING
38 1 WAVE WASHER
39 1 WASHER
40 1 NUT
Tighten and back off
1/4 turn
41 1 IDLE STABILIZING SHIFT KIT
