Mercury 175 EFI

IGNITION
90-883728 JULY 2001 Page 2A-9
Coil Plate Assembly
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 COIL PLATE
2 4 BUSHING
3 4 GROMMET
4 4 WASHER
5 2 CABLE
6 2 WASHER
7 4 SCREW (.312-18 x 1-1/4) 20 27
8 3 WASHER
9 3 SCREW (M6 x 10) 60 7
10 6 IGNITION COIL
11 12 SCREW (M6 x 25) 100 11.3
12 2 SCREW (M6 x 10) 35 4
13 6 WASHER
14 6 SPARK PLUG (NGK#BPZ8HS10) 20 27
15 6 HI-TENSION CABLE
16 2 CLIP
17 1 SENSOR-BLOCK PRESSURE [0-50 psi (0-345 kPa)]
18 1 SENSOR-SPEEDO [0-100 psi (0-689 kPa)]
19 1 COIL HARNESS
