GASOLINE STERNDRIVE INSTALLATION MANUAL
Page 4 of 137 90-860172011
Torque Specifications
NOTE: Securely tighten all fasteners not listed below.
Description
Nm lb-in. lb-ft
Gear Lube Monitor Fitting 9 80
Speedometer Pickup Barb Fitting 1.5 13
Exhaust Pipe or Block-off Plate 31 23
Power Steering Hydraulic Hose Fittings 31 23
Power Trim Pump Hose Fittings 14 125
Propeller Nut Alpha One, Bravo One and Bravo Two
1
75 55
Front Propeller Nut Bravo Three 136 100
Rear Propeller Nut Bravo Three 81 60
Rear Engine Mounts 51 38
Steering Cable Coupler Nut 48 35
Steering System (Pivot Bolts) 34 25
Sterndrive Unit Fasteners 68 50
Transom Assembly Fasteners 31 23
Seawater Pickup Fitting 5 45
Fuel Inlet Fitting
Finger tight + 1-3/4 to
2-1/4 turns with a wrench.
DO NOT overtighten.
1
Amount specified is MINIMUM.
