GASOLINE STERNDRIVE INSTALLATION MANUAL
Page 82 of 137 90-860172011
e. If necessary, rotate propeller shaft COUNTERCLOCKWISE slightly to help align
U-joint shaft splines with engine coupler splines. Then slide drive unit all the way into
bell housing.
f. Secure drive unit to bell housings using fasteners as shown. Torque the
fasteners.
22062
a
b
a-Locknut And Flat Washers
b-Locknut And Continuity Circuit Washer (No Flat Washer At This Location)
Description
Nm lb-in. lb-ft
Fasteners 68 50
6. Return remote control shift lever to the NEUTRAL position.
Bravo Models
1. Lubricate O-ring seals.
72183
a
A
a-O-ring Seals
Description
Where Used Part Number
A
2-4-C Marine Lubricant With
Teflon
O-ring Seals 92-825407A3
To Next Page
