GASOLINE STERNDRIVE INSTALLATION MANUAL
Page 20 of 137 90-860172011
SPECIAL INFORMATION ABOUT ELECTRIC FUEL PUMPS
CAUTION
The electric fuel pump and factory installed water separating fuel filter have been
carefully designed to function properly together. Do not install additional fuel filters
and/or water separating fuel filters between fuel tank and engine.
The installation of additional filters may cause:
• Fuel Vapor Locking
• Difficult Warm-Starting
• Piston Detonation Due to Lean Fuel Mixture
• Poor Driveability
Transom Connections
Installing Gimbal Housing
1. Carefully remove transom assembly from shipping carton.
2. Remove and read all tags attached to transom assembly.
22027
b
a
a-Dust Cover
b-Shipping Hardware
3. Remove the shipping hardware.
4. Remove the dust cover if boat will be shipped with drive installed.
5. Retain the serial number envelope.
To Next Page
