MAINTENANCE
81
7. Remove the drain plug and drain the oil.
8. Clean and inspect the plug O‑rings, the gearcase fill and drain
hole threads, and the plug threads.
9. Install the drain plug in the gearcase and tighten to
specifications.
10.Fill the gearcase through the top fill hole with approximately
177 milliliters (6 oz.) of oil. The oil should cover half of the
sight‑glass in the gearcase.
11.Install the fill plug and tighten to specifications.
a - Drain plug
b - Sight‑glass
c - Fill plug
Description Nm lb. in. lb. ft.
Fill and drain plugs, supercharger
gearcase
13.5 10
Tube Ref No. Description Where Used Part No.
Castrol Syntec 5W-50
Synthetic Oil
Supercharger
gearcase
Obtain Locally
