MAINTENANCE
83
Tube Ref No. Description Where Used Part No.
87
High Performance
Gear Lubricant
Transmission 92-858064K01
Capacity Fluid Type
Transmission 1 Liter (1.1 Qts.) High Performance Gear Lubricant
CHANGING NXT¹ DRIVE UNIT GEAR LUBE
1. Remove propeller, position drive unit so propeller shaft is
level.
21733
a
b
a - Oil level hole b - Level
2. Remove the water pick‑up.
a
a
a
a
b
21209
a - Fasteners
b - Water pick‑up
3. Remove the tab washer.
